BMW Series 1 F70 Wiring Diagram
BMW Series 1 F70 Wiring Diagram
Regular price
€14,00
Regular price
Sale price
€14,00
Unit price
/
per
Taxes included.
Shipping calculated at checkout.
Couldn't load pickup availability
The BMW Series 1 F70 is the fourth generation of the BMW 1 Series, which was produced from 2024 and is still in production.
The product-specific service manual, produced in 2025, covers all versions of the designated generation. It is compatible with both EU and US markets.
Series 1 F70 Wiring Diagram
| Model | Engine | Pages | Size |
|---|---|---|---|
| 116 | B38 | 3456 | 119 MB |
| 118 | B38 | 3456 | 119 MB |
| 118d | B47 | 3276 | 108 MB |
| 120 | B38 | 3458 | 119 MB |
| 120d | B47 | 3276 | 108 MB |
| 123 xDrive | B48 | 3458 | 119 MB |
| M135 xDrive | B48 | 3459 | 119 MB |
